| LVD-15 Low Voltage Detector
|
 |
|
|
FEATURES |
| |
 Bright LED and audible alarm sound when voltage is present. |
| Designed for non-contact voltage detection. |
| Can be used fo find a break in a wire. |
| Flash light function. |
| ON/OFF switch for longer battery life. |
| , , , , |
|
| The LVD-15 non-contact voltage detector is intended to check for the presence of AC voltage, signaling the user with an intermittent tone and a flashing LED. |
| The non-contact voltage detector is used to detect voltage in outlets, lighting fixtures, circuit breakers, wires, and cables or to find a break in a wire. |
|
| SPECIFICATIONS |
| |
| Voltage Detection |
50V ~ 1000V AC |
| Frequency |
50 ~ 500 Hz |
| Measurement Category |
CAT III 600V |
| Indication |
LED and Tone |
| Operating Conditions |
Temperature: 0 degree C to 40 degree C |
| |
Humidity: Less than 80% R.H. |
| |
Altitude: 2000m (6500 feet) maximum |
| Usage |
For indoor use only |
| Pollution Degree |
2 |
| Dimensions/td>
| 142(L) x 28(W) x 27(D) mm |
| Weight |
Approx. 45g (batteries included) |
| Power Supply |
1.5V AAA battery x 2 |
|
| 特 點 |
● 當感應到有電壓時，LED燈會閃亮，並且蜂鳴器會 急速響應
● 採取不直接觸設計，保障使用者人身安全
● 可應用在電線斷路的偵測
● 設計有手電筒的功能
● 耗電量小
● ：
CATⅢ 600V
|
|
| 規 格 |
 |
|
