                                                  | TEL-AL11-1 ~ TEL-AL11-5   Accessories Test Leads
 |
                                                  |  |  |


                                                  | FEATURES |
                                                  |  |
                                                  |  Wire : PVC UL 1803/18AWG, Length : 1100 +/- 30mm, Out diameter : 4.0 mm, Temperature tolenrance range : -45 degree ~ 105 degree, Braid copper wires : 170/0.08mm |
                                                  |  Terminal  105 degree angle 4mm brass banana plug (nickel plated) with caged and insulated Sheathing to avoid the brass oxidation. |
                                                  |  Rating : CAT III 1000V 15A (170/0.08) / CAT IV 1000V 15A (200/0.08) |  |
