| SPECIFICATIONS |
| |
| Volgtage/Power Input |
Universal IEC LEAD 240V/10A |
| Wiring Polarity Check |
Nominal Voltage 240Vac, Frequency 50/60Hz, Mains Voltage Tolerance +/- 10% |
| ELCB/RCD Tester |
Nominal Voltage 240Vac, Frequency 50/60Hz, Current Tolerance Proportional (current proportional to Line to Earth Voltage) |
| Universal Test Sockets |
Norminal Voltage 240Vac, Frequency 50/60Hz, Mains Voltage Tolerance +/-10%, Fuse 10A |
| Appliance Tester |
Nominal Voltage 240Vac, Frequency 50/60Hz, Mains Voltage Tolerance +/- 10%, Fuse 10A |
| Appliance Line Current Coil |
Measured by Fuse, Current Clamp Type |
| Appliance Earth Current Coil |
Measured by Fuse, Current Clamp Type |
| Dimensions |
223 (L) x 152 (W) x 67 (D) mm |
| Weight |
Approx. 318g |
| Accessories (for use with appliance test feature) |
Leakage Clamp |
Mains wiring polarity check.
