| SPECIFICATIONS |
| |
| Loop/Earth/Wires |
0.03 - 2000 Ohm (auto-ranging) |
| Prospective Short Circuit |
0 ~ 6kA at 230Vac |
| Operating Voltage |
50V ~ 275Vac (50 or 60 Hz) |
| Best Performance at Raged Voltage |
230Vac +/- 20% Max. 10A |
| Operating Temperature |
0 degree C ~ 40 degree C |
| Operating Humidity |
80% Maximum |
| Storage Temperature |
20 degree C ~ 60 degree C |
| Storage Humidity |
85% Maximum |
| Accuracy of Voltages |
+/- 1% (210 ~ 250V) +/- 3% otherwise |
| Accuracy Loops/Earth and Wire Impedances |
+/- 2% (0.05 ~ 50 Ohm) +/- 3% 500 Ohm, +/- 15% (above 500 Ohm) |
| Dimensions |
205(L) x 190(W) x 110(D)mm |
| Weight |
Appox. 1500g (battery is included) |
| Power Source |
1.5V SUM-3 (AA) x 8 |
| Accessories |
Test leads (AL-34) |
| |
Shoulder belt |
| |
Instruction manual |
| |
Batteries |
2 Lines x 16 characters Liquid Crystal Display
