| SPECIFICATIONS |
| |
| INSULATION RESISTANCE |
|
| Test Voltage (DC V) |
250V/500V/1000V |
| Output Voltage Open Circuit |
+ 10% |
| Measuring Ranges (Auto) |
0-20/0-200/0-2000M Ohm |
| Output Current |
250V : 1mA DC min. at 0.25M Ohm, 500V : 1mA DC min. at 0.5M Ohm, 1000V : 1mA DC min. at 1M Ohm |
| Accuracy |
20M Ohm : +/- (1.5%rdg+5dgt), 200M Ohm : +/- (2.5%rdg+3dgt), 2000M Ohm : +/- (5%rdg+5dgt) |
| Power Consumption |
Max. consumption current approx. 250mA |
| AC VOLTAGE RANGE |
|
| Measuring Ranges |
0-600V |
| Resolution |
1V |
| Line Frequency Range |
40-120Hz |
| Accuracy |
+/- (1.5%rdg+3dgt) |
| CONTINUITY TEST RANGES |
|
| Measuring Range (Auto) |
0 - 20/0 - 200/0 - 2000 Ohm |
| Open Circuit Terminal Voltage |
4V DC min |
| Shot Circuit Terminal Current |
200mA DC min |
| Power Consumption |
Max. consumption current approx. 160mA |
| Accuracy |
+/- (1.5%rdg+3dgt) |
| Buzzer Sounds |
under 10M Ohm |
| Display |
LCD 3-1/2 (2000 counts) |
| Power Source |
1.5V SUM-3 (AA) x 6 or equivalent |
| Dimension |
205(L) x 90(W) x 55(D)mm |
| Weight |
approx. 550g (battery included) |
| Accessories |
Test leads (TEL-AL11-A), fuse (05.A 250V), shoulder belt, carrying case, instruction manual, batteries |
68 x 34mm (1.338" x 2.677") large LCD display.
