| SPECIFICATIONS |
| |
| Insulation Resistance |
|
| Test Voltage (DCV) |
250V / 500V / 1000V |
| Output Voltage on Open circuit |
+10% |
| Measuring Ranges (Auto Ranging) |
0~20M ohm / 0~200M ohm / 0~2000M ohm |
| Accuracy |
20M ohm : +/- (1.5%rdg+2dgt) / 200M ohm: +/- (2.5%rdg+2dgt) / 2000M ohm : +/- (5%rdg+3dgt) |
| |
|
| AC Voltage |
|
| Voltage Range |
0~600V (Over 30V Buzzer Sounds) |
| Accuracy |
+/- (1.5%rdg+2dgt) |
| Impedance |
10M ohm |
| |
|
| Continuity |
|
| Measuring Range (Auto Ranging) |
0~20 ohm / 0~200 ohm / 0~2000 ohm |
| Short circuit current |
>220mA |
| Accuracy |
20 ohm: +/- (2%rdg+4dgt) / 200 ohm: +/- (1.5%rdg+2dgt) / 2000 ohm: +/- (1.5%rdg+2dgt) |
| Buzzer Sounds |
Below 10 ohm |
| |
|
| General |
|
| Display |
LCD (2000 counts) |
| Power Source |
1.5V (AA) Battery x 6 |
| Dimensions |
163(L)x102(W)x50(D)mm |
| Weight |
Approx. 470g (batteries included) |
Microprocessor controlled
