| SPECIFICATIONS |
| |
| INSULATION RESISTANCE |
|
| Test Voltage (DC V) |
500V |
| Output Voltage on Open Circuit |
Rated test voltage +10% |
| Measuring Ranges (Mid-scale value) |
0 - 1000M Ohm (20M Ohm) |
| Accuracy |
1 - 500M Ohm +/- 5% rdg, 0.7% of scale length at other ranges |
| Short Circuit Current |
1 mA |
| AC VOLTAGE |
|
| Range |
0 - 600V |
| Accuracy |
+/- 2.5% of full scale |
| GENERAL |
|
| Operating Temperature & Humidity |
0 degree ~ 40 degree C relative humidity up to 85% |
| Storage Temperature & Humidity |
- 0 degree ~ 50 degree C relative humidity up to 75% |
| Power Source |
1.5V (SUM-3. R6. AA) x 8 |
| Dimensions |
175(L) x 85(W) x 75(H) mm |
| Weight |
Approx. 560g (battery included) |
| Accessories |
Test leads |
| |
Instruction manual |
| |
Carring case (Optional) |
| |
Shoulder belt |
| |
Batteries |
High quality Taut Band movement.
